Features:
● Easy operation, high-quality optical system, high resolution, large field of view.
● Angle observation device that can realize 3D image efficiency and provide plane and 45° rotatable observation.
● The height and hole depth of three-dimensional components can be observed from different angles, and it is suitable for electronics, PCB, hardware and other industries.
Technical specification:
●Host zoom range: 0.6X~5.0X
●Zoom ratio: 1:8.3
●Maximum comprehensive magnification: 25.7X~214X (Standard configuration: Philips 27" display)
●Object field of view: Min: 1.28mm×0.96mm, Max: 10.6mm×8mm
● Observation angle: plane and 45°
●Plane area of the stage: 330mm×300mm (can be customized)
●Use height of support frame (with fine-tuning module): 260mm
●CCD( with 0.5X mount):2 million pixels,1/2” SONY chip and HDMI HD output
● Light source: adjustable 6-ring 4-division LED light
●Voltage input: DC12V
