Main technical parameters:
MicroVu has independent software/hardware development capabilities
Measurement software system:
A. Inspec full-function measurement software
B. Image capture
C. Tabulation of graphic data
Image Vision system: Vision system automatically controls light source and lens multiplier by digital
Image system: ultra high resolution stereo system
Measuring stroke: X200mm * Y150mm * Z150mm
Drivetrain: The latest Mono Rail slide technology
Servo motor: two optical rulers are used in each axis to ensure parallel accuracy
Accuracy: moving speed 10 inches /Sec(500mm/ second)
Resolution: XYZ Resolution :0.001mm
Repeatability: XYZ Repeatability 0.001mm
Accuracy: XY Accuracy 2um+L/250Z (3.0+L/150) μ
Light source system: programmable computer control light source system
Surface light source: programmable (high brightness LED) multi-layer light source of 27 ~75 degrees
Profile light source: programmable (high brightness LED)
Coaxial light (mirror table) programmable (high brightness LED)
Control: X.Y.Z three-axis joystick, mouse control function
Magnification: Programmable Zoom Lens computer control 17X~410X
The camp screen scanning system measures more than 8 points per second
Operating environment: Windows 2000
Applications: pure 32 bit
Extensibility: Network card serial,Gerber,Excellon connections
